Wood Crusher
Wood Crusher
Material : Wood waste with diameter of 50-200 mm
Size : 3-5 mm
Power : 7.5-45 kw
Capacity : 300-2000 kg/h
Guarantee : 1 year
SEND INQUIRY
We have two wood crushing choices for you: wood crusher and hammer mill. Wood crusher is designed to process wood waste with diameter of 50-200 mm into 3-5 mm powder. For wood material with diameter of less than 50 mm, you can choose wood hammer mill.
Yearmega wood crusher combines cutting and grinding, which can be used separately or as part of briquetting or wood pelletizing process.
What Materials Can be Crushed
A wide range of wood waste and cellulosic stalk material are available: wood branches, twigs, limbs, bamboo, couch grass, corn stalk, sorghum stalk, etc. The best diameter of raw material is within 50-200 mm and moisture below 30%.
Wood Crusher Feathers
1. Little body, powerful function. It combines chipping and crushing, no need for wood chipper again.
2. Crushed materials are fit to pelletizing or briquette making.
3. Adopt Japan “NSK” bearing, guaranteeing a long working life.
4. Adopt self-feeding design to ensure safe processing.
5. One motor drives, energy-saving and low cost.
Wood Crusher Technical Data
| Model | MF400 | MF600 | MF800 | MF1000 |
| Cutter Diameter (mm) |
400 | 600 | 800 | 1000 |
| Cutting Tip Amount |
4 | 4 | 6 | 6 |
| Cutting Tip Length (mm) |
95 | 180 | 260 | 300 |
| Power (kw) |
7.5 | 15 | 30 | 45 |
| Capacity (kg/h) |
300-500 | 600-700 | 800-1200 | 1800-2000 |
| Dimension (mm) |
1.1*0.7*0.95 | 1.5*0.8*1.2 | 2.1*1.1*1.4 | 2.1*1.2*1.6 |
| Weight (kg) |
450 | 700 | 1100 | 1350 |
